PPC-5xxx-9455 Panel PC
Page 16
SPECIFICATION DESCRIPTION
Interface 2ch LVDS
Supply Voltage (V) 5
Backlight 4 CCFL
Outline Dimensions (mm) 396.0 x 324.0 x 17.5
Weight (g) 2500
Table 2-5: 19” TFT LCD Monitor Specifications
2.1.4 Power Supply
The PPC-5xxx-9455 flat panel PC comes with either an ACE-A618A 180 W 1U,
ACE-4520C 200 W DC 1U or ACE-A622A 220 W 1 U RoHS compliant ATX power supply.
The PSUs have an MTBF greater than 100,000 hours.
WARNING:
Under no circumstances is the PSU case to be opened. The PSU
module is not user serviceable and there are dangerous high-voltages
inside the case. If there are any problems with the PSU module, please
contact the dealer or reseller immediately.
