PPC-5xxx-9455 Panel PC
Page 17
2.1.4.1 ACE-A618A Power Supply
Specifications for the ACE-A618A PSU module are shown in (Table 2-6).
Specification Rating
INPUT Voltage 90 V ~ 264 VAC Full Range
OUTPUT Voltage (V) +3.3 V +5 V +12 V -12 V 5 VSB
Min. Load (A) 0.3A 0.3A 1.5A 0A 0A
Max. Load (A) 14A 16A 14A 0.5A 2A
GENERAL Watt 180 W
Efficiency 68%
MTBF 100,000hrs
Temperature 0~50°C (Operating)
-20~80°C (Storage)
Humidity 5 –95% RH, Non-condensing
(Operating & Storage)
Dimension 150 mm (W) x 81.5 mm (H) x 40.5 mm (D)
Table 2-6: ACE-A618A Power Supply Specifications
2.1.4.2 ACE-4520C Power Supply
Specifications for the ACE-4520C PSU module are shown in (Table 2-7).
Specification Rating
INPUT Voltage 18 VDC ~ 36 VDC Full Range
Input Current 15A
Inrush Current 100A
