PPC-5xxx-9455 Panel PC
Page 12
SPECIFICATION DESCRIPTION
Shock 10G Acceleration, peak to peak (11ms)
Dimensions (W x D x H) PPC-5150A-9455: 410 mm x 309 mm x 110.5 mm
PPC-5170A-9455: 452 mm x 356 mm x 115 mm
PPC-5190A-9455: 483 mm x 399 mm x 115.2 mm
Net/Gross Weight PPC-5150A-9455: 7 kg/11 kg
PPC-5170A-9455: 8 kg/12 kg
PPC-5190A-9455: 12.6 kg/18.2 kg
Environment RoHS Compliant
Table 2-1: PPC-5xxx-9455 Specifications
2.1.2 Motherboard Specifications
The PPC-5xxx-9455 comes with a POS-9455 motherboard. The technical specifications of
the motherboard are listed in Table 2-2.
SPECIFICATION DESCRIPTION
CPU LGA775 Intel® Pentium® processor E2160
(1M Cache, 1.80 GHz, 800 MHz FSB)
Northbridge Intel® 945G
Southbridge Intel® ICH7
Max. FSB 800 MHz
Memory 2 x 2.0 GB (max) 400/533/667 MHz DDR2 DIMM sockets
up to 4.0 GB (total)
BIOS AMI BIOS Label
Display CRT integrated in Intel® 945G
LVDS Dual 18/24-bit TTL LCD implemented through a
Chrontel CH7308B LVDS chipset
Expansion Interface 1 x PCI slot
1 x PCIe slot
Audio HD Audio
