PPC-5xxx-9455 Panel PC
Page 19
2.1.4.3 ACE-A622A Power Supply
Specifications for the ACE-A622A PSU module are shown in (Table 2-8).
Specification Rating
INPUT Voltage 90 V ~ 264 VAC Full Range
OUTPUT Voltage (V) +3.3 V +5 V +12 V -5 V -12 V 5 VSB
Min. Load (A) 0.5A 0.5A 1A 1A 0A 0A
Max. Load (A) 14A 16A 16A 10A 0.8A 2.5A
GENERAL Watt 220 W
Efficiency 80%
MTBF 100,000hrs
Temperature 0~50°C (Operating)
-20~80°C (Storage)
Humidity 5 –95% RH, Non-condensing
(Operating & Storage)
Dimension 150 mm (W) x 81.5 mm (H) x 40.5 mm (D)
Table 2-8: ACE-A618A Power Supply Specifications
2.2 Dimensions
The dimensions of the PPC-5xxx-9455 are shown in the sections below.
