TANK-820-H61 Em b e d d e d S ys te m
P a g e 75
Device Mo d e [RS232]
The Device Mode shows Serial Port 4 provides RS-232 communications.
5.3.9.1.5 S e ria l P o rt 5 Co n fig u ra tio n
Serial Po rt [En ab led ]
Use the Serial Port option to enable or disable the serial port.
Disabled
Disable the serial port
Enabled
D
EFAULT
Enable the serial port
Ch an g e S ettin g s [Au to ]
Use the Change Settings option to change the serial port IO port address and interrupt
address.
Auto
D
EFAULT
The serial port IO port address and interrupt address
are automatically detected.
IO=2D0h;
IRQ=10
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10
IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11
IO=2D8h;
IRQ=10, 11
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10, 11
Device Mo d e [RS422/485]
The Device Mode shows Serial Port 5 provides RS-422/485 communications.
