TANK-820-H61 Em b e d d e d S ys te m
P a g e 70

IO=2C0h;
IRQ=10, 11
Serial Port I/O port address is 2C0h and the interrupt
address is IRQ10, 11

IO=2C8h;
IRQ=10, 11
Serial Port I/O port address is 2C8h and the interrupt
address is IRQ10, 11
 Device Mo d e [RS232]
The Device Mode shows Serial Port 7 provides RS-232 communications.
5.3.8.1.2 S e ria l P o rt 8 Co n fig u ra tio n
 Serial Po rt [En ab led ]
Use the Serial Port option to enable or disable the serial port.

Disabled Disable the serial port

Enabled D EFAULT Enable the serial port
 Ch an g e S ettin g s [Au to ]
Use the Change Settings option to change the serial port IO port address and interrupt
address.

Auto D EFAULT The serial port IO port address and interrupt address
are automatically detected.

IO=2C8h;
IRQ=11
Serial Port I/O port address is 2C8h and the interrupt
address is IRQ11

IO=2C0h;
IRQ=10, 11
Serial Port I/O port address is 2C0h and the interrupt
address is IRQ10, 11

IO=2C8h;
IRQ=10, 11
Serial Port I/O port address is 2C8h and the interrupt
address is IRQ10, 11
 Device Mo d e [RS232]
The Device Mode shows Serial Port 8 provides RS-232 communications.
