TANK-820-H61 Em b e d d e d S ys te m
P a g e 18
3.1 In s ta lla tio n P re c a u tio n s
During installation, be aware of the precautions below:
 Read the user manual: The user manual provides a complete description of
the TANK-820-H61, installation instructions and configuration options.
 DANGER! Disconnect Power: Power to the TANK-820-H61 must be
disconnected during the installation process, or before any attempt is made to
access the rear panel. Electric shock and personal injury might occur if the
rear panel of the TANK-820-H61 is opened while the power cord is still
connected to an electrical outlet.
 Qualified Personnel: The TANK-820-H61 must be installed and operated
only by trained and qualified personnel. Maintenance, upgrades, or repairs
may only be carried out by qualified personnel who are familiar with the
associated dangers.
 Air Circulation: Make sure there is sufficient air circulation when installing the
TANK-820-H61. The TANK-820-H61’s cooling vents must not be obstructed
by any objects. Blocking the vents can cause overheating of the
TANK-820-H61. Leave at least 5 cm of clearance around the TANK-820-H61
to prevent overheating.
 Grounding: The TANK-820-H61 should be properly grounded. The voltage
feeds must not be overloaded. Adjust the cabling and provide external
overcharge protection per the electrical values indicated on the label attached
to the back of the TANK-820-H61.
3.2 CF Ca rd In s ta lla tio n
To install the CF card, please follow the steps below:
S te p 1: Locate the CF card socket, and then loosen the thumbscrew (Figure 3-1).
