 L2 Cache: Lists the amount of storage space on the L2 cache.
 L3 Cache: Lists the amount of storage space on the L3 cache.
5.3.5 S ATA Co n fig u ra tio n
Use the SATA Configuration menu (BIOS Menu 8) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SATA Controller(s)
[Enabled]
SATA Mode Selection [IDE]
Serial ATA Port 1
Empty
Enable or disable SATA
Device.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 8: IDE Configuration
 S ATA Co n tro lle r(s ) [En ab led ]
Use the SATA Controller(s) option to configure the serial ATA controller.
 Enabled D EFAULT Enables the on-board SATA controller.

Disabled Disables the on-board SATA controller.
5.3.6 In te l TXT(LT) Co n fig u ra tio n
Use the Intel TXT(LT) Configuration menu (BIOS Menu 9) to configure Intel Trusted
Execution Technology support.
