5.2 Ma in
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version 4.6.5.3-0.19
Compliency UEFI 2.3; PI 1.2
Project Version SE21AR33.ROM
Build Date 08/28/2013 16:11:35
Processor Information
Name
IvyBridge
Brand String Genuine Intel(R) CPU
Frequency 2400 MHz
Processor ID 306a5
Stepping K0/M0
Number of Processors 2Core(s) / 4Thread(s)
Microcode Revision 7
GT Info GT2 (900 MHz)
IGFX VBIOS Version
2137
Memory RC Version 1.2.0.0
Total Memory 2048 MB (DDR3 1333)
Memory Frequency 1333 MHz
PCH Information
Name
CougarPoint
Stepping 05/B3
TXT Capability of Platform/PCH Unsupported
LAN PHY Revision N/A
ME FW Version 8.0.3.1427
ME Firmware SKU 1.5MB
SPI Clock Frequency
DOFR Support
Supported
Read Status Clock Frequnecy 33 MHz
Write Status Clock Frequnecy 33 MHz
Fast Read Status Clock Frequnecy 33 MHz
iWDD Vendor
iEi
iWDD Version SE21ER10.bin
System Date
[Thu 12/26/2013]
System Time [15:43:27]
Access Level Administrator
Set the Date. Use Tab to
switch between Data
elements.
----------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 1: Main
