TANK-820-H61 Em b e d d e d S ys te m
P a g e 22
S te p 4: Secure the HDD with the HDD bracket by four retention screws (Figure 3-7).
Figure 3-7: HDD Retention Screws
S te p 5: Reconnect the SATA signal and power cables to the TANK-820-H61.
S te p 6: Reinstall the cover.
3.4 S ys te m Fa n In s ta lla tio n
To install the optional system fan, please follow the steps below:
S te p 1: Remove the two retention screws on the rear panel and loosen the two
thumbscrews on the front panel, slide the cover inwards, and then lift the cover
up gently (Figure 3-4).
S te p 2: Unplug the SATA signal and power cables connected to the TANK-820-H61, and
then place the cover on a flat surface (Figure 3-5).
S te p 3: Attach the system fan to the TANK-820-H61 and secure it by four retention
screws (Figure 3-8).
