TANK-820-H61 Em b e d d e d S ys te m
P a g e 68
 USB Devices
The USB Devices field lists the USB devices that are enabled on the system
 Leg ac y USB Su p p o rt [En ab led ]
Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard
support. Normally if this option is not enabled, any attached USB mouse or USB keyboard
does not become available until a USB compatible operating system is fully booted with all
USB drivers loaded. When this option is enabled, any attached USB mouse or USB
keyboard can control the system even when there is no USB driver loaded onto the
system.

Enabled D EFAULT Legacy USB support enabled

Disabled Legacy USB support disabled

Auto Legacy USB support disabled if no USB devices are
connected
5.3.8 F81216 S e c o n d a ry S u p e r IO Co n fig u ra tio n
Use the F81216 Secondary Super IO Configuration menu (BIOS Menu 11) to set or
change the configurations for the serial ports.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
F81216 Secondary Super IO Configuration
Second Super IO Chip F81216 SecondIO
> Serial Port 7 Configuration
> Serial Port 8 Configuration
Set Parameters of Serial
Port 7 (COMA)
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 11: Secondary Super IO Configuration
