TANK-820-H61 Em b e d d e d S ys te m
P a g e 3
1.2 Mo d e l Va ria tio n s
The model variations of the TANK-820-H61 series are listed below.
Model No. Variations CPU Expansion Slots
TANK-820-H61
TANK-820-H61-i5/2G/2P1E-R10 Intel® Core™ i5 2xxT
Two PCI slots
One PCIe x16 slot
(PCIe x8 signal)
TANK-820-H61-i3/2G/2P1E-R10 Intel® Core™ i3 2xxT
TANK-820-H61-P/2G/2P1E-R10 Intel® Pentium® G6xxT
TANK-820-H61-i5/2G/1P2E-R10 Intel® Core™ i5 2xxT One PCI slot
One PCIe x4 slot
(PCIe x1 signal)
One PCIe x16 slot
(PCIe x8 signal)
TANK-820-H61-i3/2G/1P2E-R10 Intel® Core™ i3 2xxT
TANK-820-H61-P/2G/1P2E-R10 Intel® Pentium® G6xxT
Table 1-1: TANK-820-H61 Model Variations
1.3 Fe a tu re s
The TANK-820-H61 features are listed below:
 2nd Generation Intel® Core™ low power desktop processors for TANK-820
 On-board 2GB DDR3 memory and one DDR3 SO-DIMM slot (system max.
10GB)
 Redundant dual wild range DC power support (9 ~ 24 VDC)
 Flexible PCI/PCIe expansion slots satisfy customized requirements
 Rich I/O functions satisfy various applications
 Dual PCIe GbE LAN for high speed network applications
 One CompactFlash® socket
1.4 Te c h n ic a l S p e c ific a tio n s
The TANK-820-H61 technical specifications are listed in Table 1-2.
S p e c ific a tio n s
S ys te m
CP U 2nd Generation Intel® Core™ low power desktop processor
Ch ip s e t Intel® H61
