TANK-820-H61 Em b e d d e d S ys te m
P a g e 74

IO=3E8h;
IRQ=10
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ10

IO=3E8h;
IRQ=10, 11
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ10, 11

IO=2E8h;
IRQ=10, 11
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ10, 11
 Device Mo d e [RS232]
The Device Mode shows Serial Port 3 provides RS-232 communications.
5.3.9.1.4 S e ria l P o rt 4 Co n fig u ra tio n
 Serial Po rt [En ab led ]
Use the Serial Port option to enable or disable the serial port.

Disabled Disable the serial port

Enabled D EFAULT Enable the serial port
 Ch an g e S ettin g s [Au to ]
Use the Change Settings option to change the serial port IO port address and interrupt
address.

Auto D EFAULT The serial port IO port address and interrupt address
are automatically detected.

IO=2E8h;
IRQ=10
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ10

IO=3E8h;
IRQ=10, 11
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ10, 11

IO=2E8h;
IRQ=10, 11
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ10, 11
