KINO-QM670 Mini-ITX SBC
Page 76
ƒ Security – Sets User and Supervisor Passwords.
ƒ Save & Exit – Selects exit options and loads default settings
The following sections completely describe the configuration options found in the menu
items at the top of the BIOS screen and listed above.
5.2 Main
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version 4.6.4.0 0.01
Compliency UEFI 2.1
Project Version B185AR13.ROM
Build Date 07/01/2011 09:43:18
iWDD Vendor
ICP
iWDD Verstion B185ER12.bin
System Date
[Tue 07/06/2011]
System Time [14:20:27]
Access Level Administrator
Set the Date. Use Tab to
switch between Data
elements.
----------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 1: Main
Î BIOS Information
The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information
cannot be changed. The items shown in the system overview include:
ƒ BIOS Vendor: Installed BIOS vendor
ƒ Core Version: Current BIOS version
ƒ Compliency: The compliancy version
ƒ Project Version: The board version
ƒ Build Date: Date the current BIOS version was made
