KINO-QM670 Mini-ITX SBC
Page 89
5.3.7 H/W Monitor
The H/W Monitor menu (BIOS Menu 10) contains the fan configuration submenus and
displays operating temperature, fan speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+57 C
Accuracy: 1. -5 ~ +10 degree around 100 degree.
2. -10 ~ +15 degree around 50 degree.
System temperature
:+39 C
System FAN1 Speed :3875 RPM
System FAN2 Speed :N/A
VCC3V :+3.344 V
Vin0 :+1.064 V
Vin1 :+5.045 V
Vin2 :+12.056 V
Vin3 :+1.600 V
VSB3V :+3.344 V
VBAT :+3.216 V
> FAN 1 Configuration
> FAN 2 Configuration
Smart FAN Configuration
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 10: H/W Monitor
Î PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ System Temperature
ƒ Fan Speeds:
o System Fan1 Speed
o System Fan2 Speed
ƒ Voltages:
o VCC3V
o Vin0
