KINO-QM670 Mini-ITX SBC
Page 29
25 PERP2 26 GND
27 GND 28 1.5V
29 GND 30 SMBCLK
31 PETN2 32 SMBDATA
33 PETP2 34 GND
35 GND 36 USBD-
37 N/C 38 USBD+
39 N/C 40 GND
41 N/C 42 N/C
43 N/C 44 N/C
45 N/C 46 N/C
47 N/C 48 1.5V
49 N/C 50 GND
51 N/C 52 VCC3
Table 3-14: PCIe Mini Card Slot Pinouts
3.2.13 12V Power Connector
CN Label: PWR2
CN Type: 4-pin Molex power connector (1x4)
CN Location: See Figure 3-14
CN Pinouts: See Table 3-15
The connector supports the 12V power supply.
