Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
COM0
Console Redirection [Disabled]
> Console Redirection Settings
COM1
Console Redirection [Disabled]
> Console Redirection Settings
COM2 (Pci Bus0, Dev22, Func3)
Console Redirection [Disabled]
> Console Redirection Settings
Serial Port for Out-of-Band Management/
Windows Emergency Management Services (EMS)
Console Redirection [Enabled]
> Console Redirection Settings
Console Redirection
Enable or Disable
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 13: Serial Port Console Redirection
Î Console Redirection [Disabled]
Use Console Redirection option to enable or disable the console redirection function.
Î
Disabled D EFAULT Disabled the console redirection function
Î
Enabled Enabled the console redirection function
Î Out-of-Band Mgmt Port [COM0]
Use the Out-of-Mgmt Port option to enable or disable the Out-of-Mgmt port function.
Î
COM0 D EFAULT Enabled the COM0 function.
Î
COM1 Enabled the COM1 function.
Î
COM2 (Pci
Bus0,
Dev22,
Func3)
Enabled the COM2 function.
