KINO-QM670 Mini-ITX SBC
Page 7
1.5 Technical Specifications
KINO-QM670 technical specifications are listed in table below.
Specification KINO-QM670
Form Factor Mini-ITX
Socket Socket G2
CPU Supported Intel® Core™ i3 processor
Intel® Core™ i5 processor
Intel® Core™ i7 processor
Express Chipset Intel® QM67
Memory Two 204-pin SO-DIMM sockets support two 1066/1333 MHz
4 GB (max.) DDR3 SDRAM SO-DIMMs (system max. 8 GB)
Audio Realtek ALC892 7.1-channel HD audio codec
LAN One Intel® 82579 PHY with Intel® AMT 7.0 support
One Intel® 82583V PCIe GbE controller
Super I/O Fintek F81865
BIOS UEFI BIOS label
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
PCIe One PCIe x16 slot
One PCIe mini slot
I/O Interface Connectors
Audio Connector One internal audio connector (10-pin header)
One internal SPDIF connector (5-pin header)
One external audio line-out connector
One external mic-in connector
Display Ports One VGA port
One 18-bit or 24-bit dual-channel LVDS port
Two external HDMI ports support resolution up to 1080p
