KINO-QM670 Mini-ITX SBC
Page 90
o Vin1
o Vin2
o Vin3
o VSB3V
o VBAT
5.3.7.1 FAN 1 Configuration
Use the FAN 1 Configuration submenu (BIOS Menu 11) to configure fan 1 temperature
and speed settings.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Pc Health Status
CPU Smart Fan control [Manual Mode by PWM]
Manual Setting 70
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 11: FAN 1 Configuration
Î CPU Smart Fan control [Manual by RPM]
Use the CPU Smart Fan control option to configure the CPU Smart Fan.
Î
Full Mode The fan adjusts its speed using Full Mode settings
Î
Manual Mode
by PWM
D EFAULT The fan spins at the speed set in Manual by PWM
settings
