KINO-QM670 Mini-ITX SBC
Page 101
Î
1280x800 18bit Sets the panel type to 1280x800 18bit
Î
1366x768 24bit Sets the panel type to 1366x768 24bit
Î
1440x900 48bit Sets the panel type to 1440x900 48bit
Î
1600x900 48bit Sets the panel type to 1600x900 48bit
Î
1680x1050 48bit Sets the panel type to 1680x1050 48bit
Î
1920x1080 48bit Sets the panel type to 1920x1080 48bit
Î
1920x1200 48bit Sets the panel type to 1920x1200 48bit
5.4.2 Southbridge Configuration
Use the Southbridge Configuration menu (BIOS Menu 18) to configure the Southbridge
chipset.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
SouthBridge Configuration
Auto Power Button Status
[OFF]
Azalia [Enabled]
Azalia Internal HDMI codec [Enabled]
Restore AC Power Loss [Enabled]
PCI Express Configuration
PCIE LAN Controller (LAN2) [Enabled]
PCIE USB3 Controller [Enabled]
Control Detection of the
Azalia device.
Disabled = Azalia will be
unconditionally
disabled
Enabled = Azalia will be
unconditionally Enabled
Auto = Azalia will be
enabled if present,
disabled otherwise.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 18: Southbridge Chipset Configuration
