5.4.1 Northbridge Configuration
Use the Northbridge Chipset Configuration menu (BIOS Menu 16) to configure the
Northbridge chipset.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
NorthBridge Configuration
Memory Information
Memory Frequency
1333 Mhz
Total Memory 4096 MB (DDR3)
DIMM#1
2048 MB (DDR3)
DIMM#2 2048 MB (DDR3)
VT-d
[Disabled]
Primary Display
[Auto]
> Graphics Configuration
Check to enable VT-d
function on MCH.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 16: Northbridge Chipset Configuration
Î VT-d [Disabled]
Use the VT-d option to enable or disable VT-d support.
Î
Disabled D EFAULT Disables VT-d support.
Î
Enabled Enables VT-d support.
Î Primary Display [Auto]
Use the Primary Display option to select the graphics controller used as the primary boot
device. Select either an integrated graphics controller (IGFX) or a PCI graphics controller,
a PCI express (PEG) controller. Configuration options are listed below:
ƒ Auto D EFAULT
