3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
Audio connector 10-pin header FRONT-PANEL1
Battery connector 2-pin wafer BAT1
Backlight inverter 12 V power connector 5-pin wafer INVERTER1
DDR3 SO-DIMM socket 204-pin socket DIMM1
DDR3 SO-DIMM socket 204-pin socket DIMM2
Digital I/O connector 10-pin header DIO1
EC Debug port 18-pin header CN6
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (system) 3-pin wafer SYS_FAN1
Front panel connector 10-pin header F_PANEL1
Infrared connector 5-pin header IR1
Keyboard and mouse connector 6-pin wafer KB_MS1
LVDS connector 30-pin crimp LVDS1
PCIe mini card socket 52-pin socket CN2
Power supply 4-pin connector PWR2
Serial ATA (SATA) drive connector 7-pin SATA
S_ATA1,
S_ATA2,
S_ATA3,
S_ATA4
SATA power connector 4-pin wafer CN1, CN3
Serial port connector (RS-232) 10-pin header COM2
