When entering setup, BIOS auto detects the presence of IDE devices. BIOS displays the
status of the auto detected IDE devices. The following IDE devices are detected and are
shown in the IDE Configuration menu:
 Primary IDE Master
 Primary IDE Slave
 Secondary IDE Master
 Secondary IDE Slave
 Third IDE Master
 Third IDE Slave
The IDE Configuration menu (BIOS Menu 4) allows changes to the configurations for the
IDE devices installed in the system. If an IDE device is detected, and one of the above
listed four BIOS configuration options is selected, the IDE configuration options shown in
Section 5.3.2.1 appear.
5.3.2.1 IDE Ma s te r, IDE S la ve
Use the IDE Master and IDE Slave configuration menu to view both primary and
secondary IDE device details and configure the IDE devices connected to the system.
BIOS SETUP UTILITY
Advanced
Primary IDE Master

Device :Not Detected

Type [Auto]
LBA/Large Mode [Auto]
Block (Multi-Sector Transfer) [Auto]
PIO Mode [Auto]
DMA Mode [Auto]
S.M.A.R.T. [Auto]
32Bit Data Transfer [Enabled]
Select the type of device
connected to the system.
 Select Screen
↑ ↓ Select Item
+ -
Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 5: IDE Master and IDE Slave Configuration
 Auto-Dete cte d Drive Pa ra me ters
