4.3 Ba s ic In s ta lla tio n

This section outlines the parts that must be installed for the system to function correctly.

4.3.1 CP U In s ta lla tio n

NOTE:

To enable Hyper-Threading, the CPU and chipset must both support it.

WARNING:

CPUs are expensive and sensitive components. When installing the

CPU please be careful not to damage it in anyway. Make sure the CPU

is installed properly and ensure the correct cooling kit is properly

installed.

The LGA775 socket is shown in Figure 4-1.

Figure 4-1: Intel LGA775 Socket

To install the CPU, follow the steps below.
