IEM-945GSE ETX 3.0 Module
Page 32
Pin No. Description Pin No. Description
43
JILI_CLK
44
BL_ON#
45 NC 46 VDD_EN
47 NC 48 NC
49 NC 50 NC
51 LPT(High) 52 NC
53 VCC5 54 GND
55 PRN_STB# 56 PRN_AFD#
57 NC 58 PRN_D7
59 IR_RXD 60 PRN_ERR#
61 IR_TXD 62 PRN_D6
63 RXD2 64 PRN_INIT#
65 GND 66 GND
67 RTS2# 68 PRN_D5
69 DTR2# 70 PRN_SLIN#
71 DCD2# 72 PRN_D4
73 DSR2# 74 PRN_D3
75 CTS2# 76 PRN_D2
77 TXD2 78 PRN_D1
79
RI2#
80
PRN_D0
81 VCC5 82 VCC5
83 RXD1 84 PRN_ACK#
85 RTS1# 86 PRN_BUSY
87 DTR1# 88 PRN_PE
89 DCD1# 90 PRN_SLCT
91
DSR1#
92
MSCLK
93 CTS1# 94 MSDAT
95 TXD1 96 KBCLK
97 RI1# 98 KBDAT
99 GND 100 GND
Table 4-4: ETX 3.0 Connector X3 Pin Definitions
