IEI Integration IEM-945GSE - Manual (Page 42)

IEM-945GSE ETX 3.0 Module
Page 30
Pin No. Description Pin No. Description
69 SA13 70 DREQ3
71 SA14 72 DACK3#
73 SA15 74 IOR#
75 SA16 76 IOW#
77 SA18 78 SA17
79 SA19 80 SMEMR#
81 IORDY 82 AEN
83 VCC5 84 VCC5
85 SD0 86 SMEMW#
87 SD2 88 SD1
89 SD3 90 0WS#
91 DREQ2 92 SD4
93 SD5 94 IRQ9
95 SD6 96 SD7
97 IOCHK# 98 RSTDRV
99 GND 100 GND
Table 4-3: ETX 3.0 Connector X2 Pin Definitions
4.2.3 ETX Connector X3
CN Label: X3
CN Type: 100-pin ETX 3.0 connector
CN Location: See Figure 4-5
CN Pinouts: See Table 4-4
The standard ETX 3.0 connector locations and pinouts are shown below.
