IEM-945GSE ETX 3.0 Module
Page 3
ƒ Easy upgrading
ƒ Easy maintenance
ƒ Easy design compatibility
ƒ Low cost product development
1.4 Features
Some of the IEM-945GSE features are listed below:
ƒ Complies with ETX 3.0 form factor
ƒ Complies with RoHS
ƒ Embedded 1.6 GHz Intel® ATOM™ N270 CPU
ƒ Supports up to 2 GB of 400 MHz or 533 MHz of DDR2 memory
ƒ Supports a single Fast Ethernet connection
ƒ Support for four USB 2.0 devices
ƒ Support for one IDE channel
1.5 Overview Picture
An overview of the IEM-945GSE embedded module can be seen in Figure 1-2 and
Figure 1-3.
Figure 1-2: IEM-945GSE Overview (Front Side)
