IEI Integration ICE-945GSE v1.11 - Manual (Page 95)

ICE-945GSE COM Express Type 2 Module
Page 83
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Video Function Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
DVMT Mode Select
[DVMT Mode]
DVMT/Fixed Memory [Maximum DVMT]
Boot Display Device [Auto]
LVDS Panel Type [1024x768 18b]
LVDS1 Current Jumper Setting [640x480 18b]
Backlight Control
[Inverted]
TV Standard
[VBIOS-Default]
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 22: Video Function Configuration
DVMT Mode Select [DVMT Mode]
Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology
(DVMT) operating mode.
Fixed Mode A fixed portion of graphics memory is reserved as
graphics memory.
DVMT Mode D EFAULT Graphics memory is dynamically allocated
according to the system and graphics needs.
Combo Mode A fixed portion of graphics memory is reserved as
graphics memory. If more memory is needed,
graphics memory is dynamically allocated
according to the system and graphics needs.
DVMT/FIXED Memory [Maximum DVMT]
Use the DVMT/FIXED Memory option to specify the maximum amount of memory that
can be allocated as graphics memory. This option can only be configured for if DVMT
Mode or Fixed Mode is selected in the DVMT Mode Select option. If Combo Mode is
selected, the maximum amount of graphics memory is 128 MB. Configuration options are
listed below.
