ICE-945GSE COM Express Type 2 Module
Page 65
6.3.7 Power Configuration
The Power Configuration menu (BIOS Menu 10) allows the advanced power
management options to be configured.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Select AT/ATX Power
[ATX Power]
> ACPI Configuration
> APM Configuration
Set the ACPI state used
for System suspend
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 10: Power Configuration
Select AT/ATX Power [ATX Power]
Use the Select AT/ATX Power option to set the power mode of the system.
AT Power Use AT power
ATX Power D EFAULT Use ATX power
6.3.7.1 ACPI Configuration
The ACPI Configuration menu (BIOS Menu 11) configures the Advanced Configuration
and Power Interface (ACPI) options.
