ICE-945GSE COM Express Type 2 Module
Page 28
Pin No. Description Pin No. Description
C51 GND D51 GND
C52 PEG_RX0+ D52 PEG_TX0+
C53 PEG_RX0- D53 PEG_TX0-
C54 TYPE0# D54 PEG_LANE_RV#
C55 PEG_RX1+ D55 PEG_TX1+
C56 PEG_RX1- D56 PEG_TX1-
C57 TYPE1# D57 TYPE2#
C58 PEG_RX2+ D58 PEG_TX2+
C59 PEG_RX2- D59 PEG_TX2-
C60 GND D60 GND
C61 PEG_RX3+ D61 PEG_TX3+
C62 PEG_RX3- D62 PEG_TX3-
C63 RSVD D63 RSVD
C64 RSVD D64 RSVD
C65 PEG_RX4+ D65 PEG_TX4+
C66 PEG_RX4- D66 PEG_TX4-
C67 FAN_PWMOUT D67 GND
C68 PEG_RX5+ D68 PEG_TX5+
C69 PEG_RX5- D69 PEG_TX5-
C70 GND D70 GND
C71 PEG_RX6+ D71 PEG_TX6+
C72 PEG_RX6- D72 PEG_TX6-
C73 SDVO_DATA D73 SVDO_CLK
C74 PEG_RX7+ D74 PEG_TX7+
C75 PEG_RX7- D75 PEG_TX7-
C76 GND D76 GND
C77 FAN_TACHOIN D77 IDE_CBLID#
C78 PEG_RX8+ D78 PEG_TX8+
C79 PEG_RX8- D79 PEG_TX8-
C80 GND D80 GND
C81 PEG_RX9+ D81 PEG_TX9+
C82 PEG_RX9- D82 PEG_TX9-
