ICE-945GSE COM Express Type 2 Module

Page 29

Pin No.

Description

Pin No.

Description

C83

RSVD

D83

RSVD

C84

GND

D84

GND

C85

PEG_RX10+

D85

PEG_TX10+

C86

PEG_RX10-

D86

PEG_TX10-

C87

GND

D87

GND

C88

PEG_RX11+

D88

PEG_TX11+

C89

PEG_RX11-

D89

PEG_TX11-

C90

GND

D90

GND

C91

PEG_RX12+

D91

PEG_TX12+

C92

PEG_RX12-

D92

PEG_TX12-

C93

GND

D93

GND

C94

PEG_RX13+

D94

PEG_TX13+

C95

PEG_RX13-

D95

PEG_TX13-

C96

GND

D96

GND

C97

RSVD

D97

PEG_ENABLE#

C98

PEG_RX14+

D98

PEG_TX14+

C99

PEG_RX14-

D99

PEG_TX14-

C100

GND

D100

GND

C101

PEG_RX15+

D101

PEG_TX15+

C102

PEG_RX15-

D102

PEG_TX15-

C103

GND

D103

GND

C104

+V12

D104

+V12

C105

+V12

D105

+V12

C106

+V12

D106

+V12

C107

+V12

D107

+V12

C108

+V12

D108

+V12

C109

+V12

D109

+V12

C110

GND

D110

GND

Table 4-2: COM Express Connector CD Pin Definitions

4.2.2 COM Express Connector AB

CN Label:

J2
