ICE-945GSE COM Express Type 2 Module
Page 62
Select RS232 or RS422/RS485 [RS232]
Use the Select RS232 or RS422/RS485 option to select the Serial Port 6 signaling mode.
RS232 D EFAULT Serial Port 6 signaling mode is RS-232
RS422/RS485 Serial Port 6 signaling mode is RS-422/485
6.3.5 W83627DHG-P Hardware Health
The W83627DHG-P Hardware Health menu (
5
BIOS Menu 8) shows the operating
temperature, fan speeds and system voltages.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Hardware Health Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
SYS FAN2 Speed :N/A
CPU FAN1 Speed :N/A
+12.0V :12.056
V
+3.3V :3.376 V
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
FAN1 PWM Control
[255]
CPU FAN1 PWM Control [255]
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 8: Hardware Health Configuration
Hardware Health Monitoring
The following system parameters and values are shown. The system parameters that are
monitored are:
Fan Speeds:
o CPU Fan1 Speed
o System Fan2 Speed
Voltages:
o +12V
o +3.3V
