ICE-945GSE COM Express Type 2 Module
Page 34
4.2.3 SO-DIMM Connector
CN Label: DIMM1
CN Type: SO-DIMM connector
CN Location: See Figure 4-5
The SO-DIMM socket is for installing SO-DIMM memory.
Figure 4-5: SO-DIMM Connector Location
4.2.4 SPI Connector
CN Label: SPI1
CN Type: 6-pin connector
CN Location: See Figure 4-6
CN Pinouts: See Table 4-4
The SPI connector is for flashing new BIOS onto the SPI BIOS chip.
