ICE-945GSE COM Express Type 2 Module
Page 33
Pin No. Description Pin No. Description
A81 LVDS_A_CK+ B81 LVDS_B_CK+
A82 LVDS_A_CK- B82 LVDS_B_CK-
A83 LVDS_I2C_CK B83 LVDS_BKLT_CTRL
A84 LVDS_I2C_DAT B84 5 VSB
A85 GPI3 B85 5 VSB
A86 KBD_RST# B86 5 VSB
A87 KBD_A20GATE B87 5 VSB
A88 PCIE0_CK_REF+ B88 RSVD
A89 PCIE0_CK_REF- B89 VGA_RED
A90 GND B90 GND
A91 RSVD B91 VGA_GRN
A92 RSVD B92 VGA_BLU
A93 GPO0 B93 VGA_HSYNC
A94 RSVD B94 VGA_VSYNC
A95 RSVD B95 VGA_I2C_CK
A96 GND B96 VGA_I2C_DAT
A97 +V12 B97 TV_DAC_A
A98 +V12 B98 TV_DAC_B
A99 +V12 B99 TV_DAC_C
A100 GND B100 GND
A101 +V12 B101 +V12
A102 +V12 B102 +V12
A103 +V12 B103 +V12
A104 +V12 B104 +V12
A105 +V12 B105 +V12
A106 +V12 B106 +V12
A107 +V12 B107 +V12
A108 +V12 B108 +V12
A109 +V12 B109 +V12
A110 GND B110 GND
Table 4-3: COM Express Connector AB Pin Definitions
