ICE-945GSE COM Express Type 2 Module
Page 45
6.1 Introduction
NOTE:
The BIOS items shown below are from a ICE-945GSE installed on the
ICE-DB-9S-R10 reference carrier board. The ICE-DB-9S-R10
reference carrier board is available from iEi, contact [email protected]
or go to http://www.ieiworld.com for more information.
The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to
certain system settings. This chapter outlines the options that can be changed.
6.1.1 Starting Setup
The AMI BIOS is activated when the computer is turned on. The setup program can be
activated in one of two ways.
1. Press the D ELETE key as soon as the system is turned on or
2. Press the D ELETE key when the “Press Del to enter SETUP” message
appears on the screen. 0.
If the message disappears before the D ELETE key is pressed, restart the computer and try
again.
6.1.2 Using Setup
Use the arrow keys to highlight items, press E NTER to select, use the PageUp and
PageDown keys to change entries, press F1 for help and press E SC to quit. Navigation
keys are shown in the following table.
Key Function
Up arrow Move to previous item
Down arrow Move to next item
Left arrow Move to the item on the left hand side
Right arrow Move to the item on the right hand side
