FAN1 PWM Control [070]
This value specifies the speed of the fan. Use the + or – key to change the value.
PWM Minimum Mode: 0
PWM Maximum Mode: 255
CPU FAN1 PWM Control [070]
This value specifies the speed of the CPU fan. Use the + or – key to change the value.
PWM Minimum Mode: 0
PWM Maximum Mode: 255
6.3.6 NCT7802 Hardware Health Configuration
The NCT7802 Hardware Health Configuration menu (BIOS Menu 9) shows the
operating temperature, fan speeds and system voltages.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
NCT7802 Hardware Health Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature :64ºC/147ºF
Fan 1 Speed :N/A
FAN1 Mode Setting
[Manual Mode]
FAN1 PWM Control [250]
+Vcc :3.442 V
+V3.3 :3.425 V
VBAT :3.200 V
VCore :1.142 V Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 9: Hardware Health Configuration
FAN1 Mode Setting [Manual Mode]
Use the FAN1 Mode Setting option to configure the second fan.
