IEI Integration ICE-945GSE v1.11 - Manual (Page 43)

ICE-945GSE COM Express Type 2 Module
Page 31
Pin No. Description Pin No. Description
A17 SATA0_TX- B17 SATA1_TX-
A18 SUS_S4# B18 SUS_STAT#
A19 SATA0_RX+ B19 SATA1_RX+
A20 SATA0_RX- B20 SATA1_RX-
A21 GND B21 GND
A22 SATA2_TX+ B22 SATA3_TX+
A23 SATA2_TX- B23 SATA3_TX-
A24 SUS_S5# B24 PWR_OK
A25 SATA2_RX+ B25 SATA3_RX+
A26 SATA2_RX- B26 SATA3_RX-
A27 BATLOW# B27 WDT
A28 ATA_ACT# B28 AC_SDIN2
A29 AC_SYNC B29 AC_SDIN1
A30 AC_RST# B30 AC_SDIN0
A31 GND B31 GND
A32 AC_BITCLK B32 SPKR
A33 AC_SDOUT B33 I2C_CK
A34 BIOS_DISABLE# B34 I2C_DAT
A35 THRMTRIP# B35 THRM#
A36 USB6- B36 USB7-
A37 USB6+ B37 USB7+
A38 USB_6_7_OC# B38 USB_4_5_OC#
A39 USB4- B39 USB5-
A40 USB4+ B40 USB5+
A41 GND B41 GND
A42 USB2- B42 USB3-
A43 USB2+ B43 USB3+
A44 USB_2_3_OC# B44 USB_0_1_OC#
A45 USB0- B45 USB1-
A46 USB0+ B46 USB1+
A47 VCC_RTC B47 EXCD1_PERST#
A48 EXCD0_PERST# B48 EXCD1_CPPE#
