27. Reconnect the wires. (See Figure 54)
28. Your ATT clutch is now ready for its static test.
Apply DC voltage to the clutch coil through the
clutch control. The armature should pull against
the friction material face.
29. Install the drive belt or chain.
30. Run the clutch under its operating load.
31. Your ATT clutch may not achieve its full torque
until after a short “break-in” period. To break-in
the clutch, cycle it on and off under full load at
operating speed a minimum of ten times in quick
succession.
Your ATT clutch is now ready to run.
Figure 54
