15 Warner Electric • 800-825-9050 P-226 • 819-0355
UniModuleAssemblies
Partnumbers
Unit Enclosed(EUM) Washdown(EUM-W)
Size Voltage UniModule UniModule
50-2030 6V 5370-273-062 5370-273-104
24V 5370-273-063 5370-273-105
90V 5370-273-061 5370-273-103
180-2030 6V 5370-273-070 5370-273-120
24V 5370-273-071 5370-273-121
90V 5370-273-069 5370-273-119
210-2030 6V 5371-273-032 5371-273-060
24V 5371-273-033 5371-273-061
90V 5371-273-031 5371-273-059
ComponentParts
Item Description EUM-50 EUM-180 EUM-210
1 Armature Assembly 5370-111-011 (2) 5370-111-013 (2) 5371-111-005 (2)
2 Armature Hub 540-1638 540-1642 540-0741
2a Key 590-0043 590-0084
3 Retaining Ring 748-0445 748-0676
4 Lockwasher 950-0121 (6)
5 Capscrew 797-0081 (6)
6a Retaining Ring 748-0113 748-0101 748-0112
6b Retaining Ring 748-2002
7 Ball Bearing 166-0149 166-0101 166-0142
8 Endbell/Brake 456-1014 456-1019 456-1017
9 Brake Magnet
6 Volt 5370-631-037 5370-631-002 5371-631-002
24 Volt 5370-631-038 5370-631-005 5371-631-005
90 Volt 5370-631-036 5370-631-003 5371-631-003
9a Set Screws
10 Clutch Field/End Bell Assembly
6 Volt 5370-451-082 5370-451-090 5371-451-002
24 Volt 5370-451-083 5370-451-091 5371-451-005
90 Volt 5370-451-081 5370-451-089 5371-451-003
11 Rotor 5370-751-033 5370-751-034 5371-751-006
11a Screw 797-1294 (4) 797-1214 (5) 797-0081 (6)
11b Washer 950-0102 (4) 950-0102 (5) 950-0121 (6)
12 Shaft/Clutch 798-0047 798-0124 798-0123
13 Cover Plate 686-1055 686-1055 686-1055
13a Screws 797-0575 (4) 797-0575 (4) 797-0575 (4)
14 Center Housing 535-0176 535-0176 535-0177
15 Conduit Box 5370-101-042 5370-101-042 5370-101-042
16 Shaft/Brake 798-0046 798-0085 798-0051
16a Key 590-0029 (2) 590-0029 (2) 590-0019 (2)
17 Retaining Ring 748-0113 (2) 748-0101 748-0112
18 Retaining Ring 748-0017 748-0202
19 Assembly Bolts 797-1477 (2) 797-1477 (2) 797-1476 (2)
20 Connector 280-0038 280-0038 280-0038
21 Bearing 166-0149 166-0101 166-0142
22 Bearing 166-0155 166-0143 166-0144
23 Spacer 807-0062 807-0061
24 Bearing 166-0155 166-0143 166-0144
25 Washer 950-0441 950-0441 950-0441
26 Insulator 572-0327 572-0327 572-0327
EUM-WUniqueParts
12W Shaft/Clutch 798-0264 798-0261 798-0260
14W Center Housing for Washdown 535-0181 535-0181 535-0182
15W Conduit Box Kit 5370-101-045 5370-101-045 5370-101-045
16W Shaft/Brake 798-0263 798-0262 798-0259
20W Conduit Connector 280-0058 258-0058 258-0058
27W Washdown Mounting Kit 5370-101-051 5370-101-051 5371-101-027
28W Gasket/Seal Repair Kit 5370-101-058 5370-101-058 5371-101-032
