Enclosedunimodulecombinations – Warner Electric EUM-50_EUM-100_EUM-180_EUM-210_EUM-215 User Manual
Page 10
10
Warner Electric • 800-825-9050
P-226 • 819-0355
EUM1020 Motor mounted UniModules
E
Size
A
B
C
D
EUM
EUM-W
F
G
H
I
50
6.750
4.844
1.813
.625
7.270
6.915
2.427
5.936
7.687
2.430
100
6.750
4.844
1.890
.625
7.270
6.915
2.427
5.936
7.687
2.430
180
6.828
4.844
1.890
.875
7.270
6.915
2.427
5.936
7.687
2.430
210
8.891
5.922
2.500
1.125
10.000
10.00
3.053
7.146
10.187
3.375
215
8.891
5.922
2.500
1.375
10.000
10.00
3.053
7.146
10.187
3.375
EnclosedUniModuleCombinations
DimensionsEUM-1020
E
3.125
2.188
G
C
min.
D
B
20
Brake
10
Motor
Clutch
H
Optional
Fan Kit
I
F
A
2.203
Optional
Conduit Box
Note:Washdown Unimodules (EUM-W) do not have a finned housing.
E
F (4) slots
B
D
C
A
MotorMount(M)
PartNo.
Size
A
B
C
D
E
F
EUM
EUM-W
50
9.250 8.250 11.000 8.000 3.500 .796 x .406 5370-101-010 5370-101-048
100 9.250 8.250 11.000 8.000 3.500 .796 x .406 5370-101-010 5370-101-048
180 9.250 8.250 11.000 8.000 4.500 .796 x .406 5370-101-012 5370-101-049
210 11.500 10.500 12.000 9.000 5.250 .750 x .406 5371-101-012 5371-101-026
215 11.500 10.500 12.000 9.000 5.250 .750 x .406 5371-101-012 5371-101-026
