Warner Electric Electro-Module EM-50, EM-100, EM-180, EM-210, EM-215 User Manual
Page 2
2
Warner Electric • 800-825-9050
P-213 • 819-0303
Contents
Pre-Installation Instructions . . . . . . . . . . . . . . . .2
Installation Instructions . . . . . . . . . . . . . . . . . . .4
Setting Airgap . . . . . . . . . . . . . . . . . . . . . . . . . .5
Electrical Coil Data . . . . . . . . . . . . . . . . . . . . . .8
Burnishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .9
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Overhung Load Data . . . . . . . . . . . . . . . . . . . .11
Dimensions and Specifications
EM-50-10 . . . . . . . . . . . . . . . . . . . . . . . . . .12
EM-100-10 . . . . . . . . . . . . . . . . . . . . . . . . .12
EM-180-10 . . . . . . . . . . . . . . . . . . . . . . . . .12
EM-210-10 . . . . . . . . . . . . . . . . . . . . . . . . .12
EM-50-20 . . . . . . . . . . . . . . . . . . . . . . . . . .13
EM-100-20 . . . . . . . . . . . . . . . . . . . . . . . . .13
EM-180-20 . . . . . . . . . . . . . . . . . . . . . . . . .13
EM-210-20 . . . . . . . . . . . . . . . . . . . . . . . . .13
EM-215-20 . . . . . . . . . . . . . . . . . . . . . . . . .13
EM-50-30 . . . . . . . . . . . . . . . . . . . . . . . . . .14
EM-100-30 . . . . . . . . . . . . . . . . . . . . . . . . .14
EM-180-30 . . . . . . . . . . . . . . . . . . . . . . . . .14
EM-210-30 . . . . . . . . . . . . . . . . . . . . . . . . .14
EM-50-40 . . . . . . . . . . . . . . . . . . . . . . . . . .15
EM-100-40 . . . . . . . . . . . . . . . . . . . . . . . . .15
EM-180-40 . . . . . . . . . . . . . . . . . . . . . . . . .15
EM-210-40 . . . . . . . . . . . . . . . . . . . . . . . . .15
EM-10-20 . . . . . . . . . . . . . . . . . . . . . . . . . .16
EM-10-40 . . . . . . . . . . . . . . . . . . . . . . . . . .17
EM-20-30 . . . . . . . . . . . . . . . . . . . . . . . . . .18
EM-30-40
. . . . . . . . . . . . . . . . . . . . . . . . .19
NEMA Frame Standards . . . . . . . . . . . . . .20
Warranty . . . . . . . . . . . . . . . . . . . .Back Page
Pre-Installation Instructions
A. Before installing the Electro-Module to a
motor or reducer, make certain that the EM
size and NEMA frame dimensions match
according to Table 1.
Corresponding
EM
NEMA
Shaft
C-Face
Size
Frame Sizes
Dia.
Pilot Dia.
50
48Y/56C
5/8
4-1/2
100
48Y/56C
5/8
4-1/2
180
143TC/145TC
7/8
4-1/2
210
182TC/213TC
1-1/8
8-1/2
215
213TC/215TC
1-3/8
8 1/2
Table 1
B. Check the motor for shaft endplay. If the
shaft can be moved axially .030” or more, the
module should not be installed since exces-
sive thrust may occur between the rotor and
field. The motor should not be used unless
the endplay can be reduced.
C. Install your specific modular combination
according to the installation steps specified
in Table 2. Use only those steps indicated for
each combination.
Failure to follow these instruc-
tions may result in product damage, equipment
damage, serious or fatal injury to personnel.
