ADP30x Probe
Specifications
Nominal Characteristics
Nominal characteristics describe parameters and attributes that are guaranteed
by design, but do not have associated tolerances.
Sensitivity:
ADP300 1 V/div to 350 V/div
ADP305 200 mV/div to 350 V/div
Input Configuration True Differential, + and – inputs
Maximum Input Voltage 1000 V rms, either input to
ground, CAT III.
1400 Vp, between inputs
Output Configuration Single ended, Ground referenced
Intended Output Load 1 MΩ
Output Connector ProBus
Input Attenuation ÷100 or ÷1000
Bandwidth Limit Filter 20 MHz
(ADP305 only)
Interface ProBus
Oscilloscope Compatibility Teledyne LeCroy LT or LC series
oscilloscopes with firmware version 8.5 or
higher; or X-Stream oscilloscopes.
(Not available for 9300 series oscilloscopes)
Warranted Characteristics
Warranted characteristics are parameters with guaranteed performance. Unless
otherwise noted, tests are provided in the "Performance Verification Procedure"
for all warranted specifications.
Low Frequency Accuracy ±1% of reading (÷1000 Atten)
(probe only) ±2% of reading (÷100 Atten)
4 923079-00 Rev A
