Operator’s Manual

Probe Volts/div

PRx:VOLT_DIV,PRx:VDIV

Command/Query

Description

The PRx:VOLT_DIV command sets the vertical sensitivity at the

ADP30x input. The effective gain of the differential probe is

factored into the vertical sensitivity.
The valid range of arguments is fixed by the probe type. If an out-

of-range value is entered, the oscilloscope will set the vertical

sensitivity to the closest value and set the VAB bit (bit 2) in the STB

probe input of the specified channel.

Command Syntax

:Volt_DIV
:={PR1, PR2, PR3, PR4}

:={200 mV to 350 V}

for ADP350

:={1 V to 350 V}

for ADP300

Query Syntax

:Volt_DIV?

Response Format

:VDIV

Example

The following command sets the vertical sensitivity at the probe tip

of the ADP30x probe connected to channel 3 to 2 Volts/div:

CMD$="PR3:VDIV 2":CALL IBWRT(SCOPE%,CMD$)

NOTE: The suffix V is optional

923079-00 Rev A
