Operator’s Manual
Description of Accessories
Plunger Hook Clip (1 Red, 1 Blue)
Insulated, 1000 V, CAT II. Designed to attach to
wire leaded parts, the overall length is 158 mm
(6.22 inches), and the hook extends 8 mm (0.31
inch) when the plunger is fully pressed.
Safety Alligator Clip (1 Red, 1 Blue)
Insulated, 1000 V, CAT III. Designed to attach to
large components, such as busbars and large
bolts, the overall length is 90 mm (3.54 inches)
and the jaw opens to 22 mm (0.87 inch) max.
Plunger Jaw Clip (1 Red, 1 Blue)
Insulated, 1000 V, CAT II. The clip is designed to
securely grasp thick wires, cables, ground
leads, rails, and even screw heads. The overall
length is 175 mm (6.89 inches). The steel jaw
extends 12 mm (0.48 inch) and opens to 25 mm
(1 inch).
923079-00 Rev A 9
