ADP30x Probe
Performance Verification
This procedure can be used to verify the warranted characteristics of the
ADP30x series Active Differential Probes.
If the product does not meet specifications, it should be returned to a Teledyne
LeCroy service center. There are no user accessible adjustments, so there is no
adjustment procedure.
Test Equipment Required
The following table lists the test equipment and accessories (or their
equivalents) that are required for performance verification of the ADP30x Active
Differential probe. This procedure is designed to minimize the number of
calibrated test instruments required. Because the input and output connector
types may vary on different brands and models of test instruments, additional
adapters or cables may be required.
Only the parameters listed in boldface in the "Minimum requirements" column
must be calibrated to the accuracy indicated.
Description Minimum Requirements Test Equipment Examples
Digital Multimeter DC: 0.1% Accuracy
AC: 0.2% accuracy to
measure 700 mV at 70 Hz Agilent Technologies
34401A
Fluke 8842A-09
Keithley 2001
Function Generator Sine Wave output waveforms
20 Vp-p Agilent Technologies
33120A
Stanford Research Model
DS340
Leader LAG-120B
BNC Coaxial Cable Male-to-Male 50
Ω Cable
Pomona 5697-36
Calibration Fixture ProBus Extender Cable Teledyne LeCroy PROBUS-
CF01
Banana Plug Adapter Female BNC-to-Dual Banana
Plug Pomona 1269 or Mueller
BU-00260
Insulated Banana Plug
Insulated Banana
Couplers (2) Insulated BNC-to-Shrouded
Banana Plug Mueller BU-5671-B-12-0
Mueller BU-32601-2 (Red)
Mueller BU-32601-6 (Blue)
22 923079-00 Rev A
