Package contents, An-100-sw-r-5 package contents, An-100-sw-r-8/16/24 package contents – Staub Electronics AN-100-SERIES ARAKNIS - 100-SERIES 8-PORT UNMANAGED GIGABIT SWITCH WITH REAR PORTS User Manual
Page 7: Recommended for installation, 3 package contents, 4 recommended for installation, Figure 1, Figure 2
7
www.araknisnetworks.com
|
Support: 866.838.5052
1.3 —
Package Contents
1.4 —
Recommended for
Installation
• #2 Phillips screwdriver
• Screws and Anchors - for wall-mount installation if applicable (use a fastener rated and
specified for use in the wall material that can safely hold the weight of the model in use)
• Rack screws- for rack installation
• Drill and Drill Bit- for installation of wall-mount screws or anchors
1
|
INTRODUCTION
Figure 1.
AN-100-SW-R-5 Package Contents
Figure 2.
AN-100-SW-R-8/16/24 Package Contents
AN-100-SW-R Gigabit Ethernet Switch (1)
Rack Mount Kit (1)
Rack Mount Kit (1)
Rubber Feet (1)
Rubber Feet (1)
AC Power Cord (1)
DC Power Supply (1)
Quick Installation Guide (1)
Quick Installation Guide (1)
AN-100-SW-5 Gigabit Ethernet Switch (1)
Screws (4)
Wall Anchors (4)
