B-500-MTRX-230 Installation Manual
Pg. 30
© 2013 Binary
™
15. Specifications
16. Warranty
2
year
2 Year Limited Warranty
This SnapAV
®
product has a 2-year Limited Warranty. This warranty includes parts and labor repairs
on all components found to be defective in material or workmanship under normal conditions of
use. This warranty shall not apply to products which have been abused, modified or disassembled.
Products to be repaired under this warranty must be returned to SnapAV or a designated service
center with prior notification and an assigned return authorization number (RA).
TECHNICAL
B-500-MTRX-230-8X16
B-500-MTRX-230-16X16
HDMI Compliance
HDMI 3D
HDCP Compliance
Yes
Video Bandwidth
6.75Gbps
HDMI over UTP Transmission
Resolution
Cat5e/ Cat6
Cat6a
1080i / 720p 24-bit color
200ft
230ft
Full HD 1080P 24-bit color
200ft
230ft
Full HD 1080P 36-bit deep color
200ft
230ft
Input TMDS Signal
1.2 Volts (peak-to-peak)
Input DDC Signal
5 Volts (peak-to-peak, TTL)
ESD Protection
(1) Human body model — ±15kV (air-gap discharge) & ±8kV
(contact discharge) (2) Core chipset — ±8kV
IR Signal (Bi-directional)
Carrier frequency: 20-60kHz
CONNECTIONS
HDBaseT Link
16 x RJ45
HDMI
24 x HDMI Type A (19-pin female)
32 x HDMI Type A (19-pin female)
IR (In)
1 x 3.5mm Mono
All IR (Out)
1 x 3.5mm Mono
IR Input to Room
16 x 3.5mm Mono
IR Output to Source
16 x 3.5mm Mono
RS232 Control Port
DB9
Power
Polarized
Ethernet
1 x RJ45
MECHANICAL
Housing
Metal enclosure
Dimensions (W x H x D)
17.32” x 5.20” x 12.72” (without ears)
Weight
21 lbs.
Power Supply
12V DC 11.25A
Power Consumption
110w (max)
120w (max)
Operation Temperature
32~104°F
Storage Temperature
-4~140°F
Relative Humidity
20~90% RH (no condensation)
Certifications and Compliance
Product: CE, FCC
Power Supply: CE, FCC, UL
