Foredom K.1050 User Manual
Page 3
2
Components
1
Control Unit (HP4-717)
2
Speed Display
3
Motor On/Off Switch
4
Motor On Indicator Light
5
Auto Cruise Switch
6
Auto Cruise On Indicator Light
7
Speed Control Knob
8
Forward/Reverse Selector Switch
9
Forward/Reverse Indicator Light
19
Handpiece (Brushless DC
Micromotor H.MH-150)
20
Handpiece Motor Cord
21
Handpiece Cradle
(HP4-933)
22
Handpiece Holder
23
Chuck Wrench
24
Foot Pedal (HP7-7060)
25
Foot Pedal Cord
26
Power Cord
10
Hand/Foot Selector Switch
11
Hand/Foot Indicator Light
12
Power On/Off Switch & Light
13
Handpiece Plug Outlet
14
Foot Pedal Plug Outlet
15
Power Cord Plug Outlet
16
Fuse Holder with spare fuse
17
Test Bur
18
3/32
″ Collet (1/8″ is optional)
Collet part numbers and sizes
are listed on page 7.
3
4
8
9
5
6
7
10
11
12
15
14
16
13
1
2
18
17
20
19
23
25 24 26
21 22
