(Reference) How the indicator lamps on the simple absolute unit change in each condition
RDY/ALM
Steady green Steady red
Operation
{
-
The system is normal.
-
{
The system is experiencing
an error.
STATUS1
Steady green Steady red
Operation
{
-
Absolute reset has been completed (with steady green
RDY).
-
{
Absolute reset is not yet completed (with steady green
RDY).
-
{
FPGA communication error (with steady red RDY)
STATUS0
Steady green Steady orange Steady red
Operation
{
-
-
The battery is fully charged.
-
{
-
The battery is charging.
- -
{
The battery is not connected.
(Note)
The unit is in the update mode. Disconnect the battery and set piano switch 3 to the OFF position.
For more information on how to set the piano switches, refer to 5.1.1, “Piano Switch Settings.”
RDY/ALM
Blinking green Blinking red
Operation
{
{
Update mode (Note)
