Page 36
18
4.2.2
ACON Controller Cable
* Make sure the connectors at the ends of the cable are oriented correctly.
ACON controller end
Simple absolute unit end
Stripped
length of
sheath: 25
Stripped
length of
sheath: 25
(Red)
White
Blue/Red
Orange/White
Blue
Orange
Green
Brown
Gray
Red
Black
Yellow
Pink
Purple
Green/White
Drain
Drain
White
Blue/Red
Orange/White
Green/White
Blue
Orange
Green
Brown
Gray
Red
Black
Yellow
Pink
Purple
Signal
name
Shield, braided
Signal
name
(Red)
